ANSI 1500LBS Forged Steel Manual High-Pressure Self-Sealing Welded Gate Valve
I. Product Overview: Precision Interception for High-Pressure Applications
Newway’s ANSI 1500LBS forged steel manual high-pressure self-sealing welded gate valve, designed to ASME B16.34 standards, uses A105 forged carbon steel or 316 stainless steel, developed for high-pressure pipeline systems in petroleum, chemical, and power industries. The valve employs a self-sealing structure that uses medium pressure to dynamically seal the bonnet and body, combined with a bevel gear drive mechanism, maintaining zero-leakage interception performance under Class 1500 (PN250) high-pressure conditions. Its core advantages lie in the high-strength impact resistance of forged steel and the reliability of the self-sealing structure in high-pressure scenarios, suitable for media control (water, steam, oil) at -29℃~425℃.
II. Key Attribute Parameters: Comprehensive Technical Specifications
|
Parameter Category |
Technical Indicators |
|
Nominal Diameter Range |
DN50~DN600 (NPS2″~NPS24″), supporting raised face flanges, ring joint faces, and butt weld ends |
|
Pressure Class |
Class 1500 (PN250), compatible with Class 600/900/2500 pressure systems |
|
Execution Standards |
Design: API 600, ASME B16.34; Face-to-Face: ANSI B16.10; Welding: ANSI B16.25 |
|
Material System |
– Body/bonnet: A105 forged carbon steel (≤425℃), F316 stainless steel (≤200℃); |
|
Connection Types |
Butt Weld (BW), Raised Face (RF) flanges, Ring Type Joint (RTJ), compliant with ANSI B16.5 |
|
Operation Mode |
Manual bevel gear drive, customizable with electric/pneumatic actuators |
|
Applicable Media |
Water, steam, oil products, natural gas, and non-corrosive industrial fluids |
