Newway Flange 3-Way Ball Valve: T/L Type Cast Stainless Steel Industrial Fluid Control Solution

I. Technical Overview

Newway flange 3-way ball valve features T/L type dual structure, covering DN15~DN300 sizes, suitable for water, oil, gas and other media diversion, confluence and direction control. Made of 304/316 cast stainless steel, with nominal pressure PN16~PN64 (150~600LB) and working temperature -20℃~232℃, it is widely used in chemical, petroleum, water treatment and HVAC industries. The L-type structure realizes 90° direction switching, while the T-type supports arbitrary connection of three channels, complying with ISO, ANSI, DIN standards for flexible fluid control.

II. Core Features

(A) T/L 3-Way Structure

L-Type Flow Control: Connects two perpendicular channels for direction switching (e.g., pipeline diversion), with ±0.5° accuracy;

T-Type Diversion/Confluence: Connects three channels for medium splitting (1 inlet to 2 outlets) or mixing (2 inlets to 1 outlet), with flow resistance coefficient ≤0.8;

Bidirectional Sealing: PTFE+carbon fiber seats with spring preloading ensure bubble-tight sealing (leakage ≤1×10⁻⁹m³/s), API 598 Class IV compliant.

(B) Material & Design Advantages

(C) Operation & Maintenance

Manual Drive: Standard extended handle (≤120N·m), gearbox option for DN150+ models, 50% less effort;

Quick-Disassembly: Symmetric bolted bonnet allows 15-min seal replacement, 40% higher maintenance efficiency;

Longevity: 50,000-cycle tested with ≥95% sealing retention (industry standard: 30,000 cycles).

Product Overview

III. Manufacturing & QC

(A) Precision Casting

Body Forming: Silica sol casting, surface roughness Ra≤12.5μm, UT-tested for defects (≥Φ2.0mm);

Ball Machining: CNC turned and ground to ≤0.01mm roundness, ≤0.02mm fit with seats;

Surface Treatment: Passivated (ASTM A967), optional epoxy coating (200μm) for marine environments.

(B) Quality Control

Testing: 1.5x hydrostatic (30-min hold), 1.1x gas-tight test (helium leakage ≤1×10⁻⁹m³/s);

Certifications: CE, SIL certified, API 6D compliant models available;

Capacity: 50,000 pcs/month, 7-day delivery for standard orders.

Application

IV. Applications

Chemical reactor material switching: T-type for precise diversion, ±1% error with DCS;

Oil pipeline direction control: L-type in sulfurous crude, 316 SS lasts 5 years;

HVAC water systems: DN200 T-type for flow regulation, 12% energy saving;

Food-grade applications: 304 electropolished body (Ra≤0.4μm), FDA compliant for CIP systems.
